Bobcat S510 Product Description
The Bobcat S510 is a compact, high-performance skid-steer loader from Bobcat’s M-series, designed for tight spaces and multi-tasking operations. Powered by a 55HP Kubota V2403 Stage V engine, it delivers 37% higher torque than previous models, ensuring strong power with low fuel consumption(Bobcat). Its radial lift path provides excellent visibility and reach, while the compact frame enables zero-radius turning for maximum agility(Bobcat). The S510 features a robust hydraulic system, durable cast-steel lift arms, and a comfortable cab with intuitive controls, making it ideal for construction, landscaping, agriculture, and municipal work.
Product Parameters
- Model: Bobcat S510 Skid-Steer Loader
- Engine: Kubota V2403 Stage V Diesel(Bobcat)
- Rated Power: 55HP (36.5kW) @ 2700rpm(Bobcat)
- Max Torque: 158.6Nm @ 1600rpm(Bobcat)
- Rated Load (ISO): 851kg(Bobcat)
- Tipping Load: 1619kg(Bobcat)
- Operating Weight: 2686kg(Bobcat)
- Hydraulic Flow: 64.7L/min(Bobcat)
- Lift Height (Hinge Pin): 2930mm
- Travel Speed: 11.8km/h (17.3km/h optional)
- Fuel Tank Capacity: 93.7L(Bobcat)
Core Advantages
Compact & Agile Design
With a narrow frame and zero-radius turning, the S510 maneuvers effortlessly in tight job sites, indoor spaces, and urban construction areas.
Powerful & Efficient Performance
The Stage V engine delivers high torque at low RPM, providing strong digging and lifting power while reducing fuel consumption and emissions(Bobcat). The robust hydraulic system ensures fast cycle times and efficient operation.
Durable & Reliable Build
Cast-steel lift arms, reinforced chassis, and heavy-duty components withstand tough working conditions, minimizing downtime and maintenance costs.
Versatile Attachment Compatibility
Equipped with the Bob-Tach quick coupler, the S510 accepts over 40 attachments (buckets, forks, augers, etc.), transforming it into a multi-functional tool for various tasks(Bobcat).
